These lights are very good quality and have a light intensity of about a 25watt bulb. Great light output such that is lights up more than 1 step that it's attached to. Only challenge is assuring the mounting holes in the step wall have enough material between the cutout and screw hole. I used outdoor double sided tape (3M Extreme) to assure the light stays attached to the step wall.
NOTE: Here is some data on the cutout opening dimensions for mounting into wood steps/walls and concrete steps/walls. The hole pattern is extremely close to the edge of the opening. So that you cannot cut the length of your opening to much or you'll not be able to use the screws for the mounting holes. Your opening cannot exceed 7-1/2" Long (go with 7-3/8" Long and chisel/file it to fit) on the width you have plenty of flexibility, the opening can be 2-1/2" to 2-3/4" wide. See the pics with the tape measure to help you better size your mounting surface.
The other option is to use this version which is a flush mount to any type box: Hinkley 1557BZ Landscape Taper, Deck Sconce, Bronze.
Hope this helps....
| Brand | Hinkley |
|---|---|
| Color | Satin Black |
| Material | Aluminum |
| Style | Modern |
| Light fixture form | Recessed |
| Room Type | Bedroom, Dining Room, Kitchen, Living Room |
| Product Dimensions | 1"L x 5"W x 3.5"H |
| Specific Uses For Product | General Purpose |
| Indoor/Outdoor Usage | Outdoor |
| Power Source | Transformer |
| Installation Type | Screw-In |
| Special Feature | Dimmable, Integrated, Low Voltage, Water Resistant |
| Control Method | App |
| Light Source Type | Integrated |
| Finish Type | Satin Black |
| Shade Material | Aluminum |
| Number of Light Sources | 1 |
| Voltage | 12 Volts |
| Light Color | Warm White |
| Included Components | Light Bulb(s) Included |
| Warranty Type | Manufacturer Warranty |
| Lighting Method | LED |
| Item Weight | 0.37 Pounds |
| Number of Items | 1 |
| Wattage | 1.9 watts |
| Bulb Base | GU24 |
| Controller Type | Does Not Apply |
| Switch Type | Push Button |
| Unit Count | 1.0 Count |
| Water Resistance Level | Water Resistant |
| Connectivity Protocol | Does Not Apply |
| Brightness | 160 Lumen |
| Efficiency | 84.21 lumens/watt |
| Mounting Type | Wall Mount |
| Shade Color | Satin Black |
| Fixture Type | Non Removable |
| Assembly Required | No |
| Manufacturer | Hinkley |
| Color Temperature | 2700 Kelvin |
| Size | Horizontal Step Light |
| UPC | 640665156935 |
| Light Output Maximum | 160 Lumens |
| Recommended Uses For Product | Light Fixture |
| Model Name | Step 12V Horizontal |
| Part Number | 1563SK |
| Item Weight | 5.9 ounces |
| Item model number | 1563SK |
| Finish | Satin Black |
| Item Package Quantity | 1 |
| Plug Format | A- US style |
| Special Features | Dimmable, Integrated, Low Voltage, Water Resistant |
| Batteries Included? | No |
| Batteries Required? | No |
| Warranty Description | 2 year limited. |
